Automatic operation for all heater stages with one touch
Control via device or touch keys
Turbine fan for hot air circulation with two speeds
Fan shutter helps with fast ignition
High-quality thermal coating baked in oven
Wide crystal interface size 143×254 mm × 4
Larger view of panoramic fire
02. Operating Instructions:
Fill the kerosene tank up to the line inside the filter
Connect the heater cable to the electrical outlet (220V)
Set the regulator indicator to the middle
Press the start button on the control device and the program will run automatically for 15 minutes starting with the igniter, then the fan shutter, then the turbine fan
Open the kerosene valve 4 complete turns
You can intervene at any moment to stop or start the program and control the igniter or fans as needed
If the heater does not ignite, raise the regulator indicator two levels then press the start button again. Do not repeat this process more than twice consecutively as it causes igniter damage (look for the reason for non-ignition in dirty kerosene, chimney draft, or weak electricity)
03. Important Notes:
The heater legs must be adjusted to be completely level and lock the adjustment after calibration
Attention must be paid to the heater standing completely level on the ground to ensure the kerosene regulator (carburetor) works correctly
On sunny days, place a small piece of cloth soaked in kerosene in the shape of a ball in the chimney pipe before operation to speed up the ignition process
Empty the kerosene tank and dry it with a cloth at the end of winter
Chemical materials or water are prohibited for cleaning the combustion device to prevent device damage
